Ceiling expansion screw assembly
Surface treatment: multicolor electroplating.
characteristic:
1. The special bump design of the casing prevents the casing from idling, so it can be used in the case of expansion construction, and it can also be used if the depth is too deep.
2. Hollow cement can also be used.
Purpose:
Installation ceiling, water and electricity, heating, moving and other equipment hoisting.
Model | Tooth diameter | External diameter (mm) | Overall length (mm) | Director (mm) | Drilling depth (mm) | Cement strength 20.58MPa | |
Ultimate tensile strength (N) | Ultimate shear resistance (N) | ||||||
EAD650 | M6 | 8 | 50 | 35 | 50 | 5880 | 4900 |
EAD855 | M8 | 10 | 55 | 40 | 55 | 7840 | 7840 |
EAD1065 | M10 | 12 | 65 | 50 | 65 | 13720 | 13720 |
EAD1275 | M12 | 16 | 75 | 55 | 75 | 17150 | 19600 |
Safety rate: static load 4-5, dynamic load 8-10.
Remarks: the whole tooth screw is calculated separately.
