| Model | KS 52/34 |
| Material / surface treatment | Q235，16Mn/FV,WB | |
| Design load｛KN｝ | It can bear dynamic load | |
| ≥C25 | 33.9（C20/25） | |
| （The maximum design value specified in the technical standard，C25） | 38.5（C30/37） | |
| Anchor shape | C | I | R |
| Installation height | 153 | 160 | 365 |
| Fillings | Polystyrene particle filling（PS） | |
Polystyrene particle anchor shape C = round anchor (standard pattern), I = welded anchorage in exceptional cases, r = extended reinforcement welded (for thin concrete material) filling
| Length［mm] | Number of anchors(no.) | Number of anchors s |
| Short block | 150 | 2 | 100 |
| 200 | 2 | ≤150 |
| 250 | 2 | ≤200 |
| 300 | 2/3 | ≤250 |
| 350～550 | 3 | ≤250 |
| 600～800 | 4 | ≤250 |
| 850～1050 | 5 | ≤250 |
| Truncation length | 1050＜L＜6000 Customized | ≤250 |
| Delivery length | 6000（-0/+50） | 25 | ≤250 |
